Auto COB Liquid Dispensing Machine

PME-R650A

* Use Windows2000/XP Operating System.

* Interpolate lines or acres for three-dimensional dispensing that accurate continuous path motion.

* Large data storage capacity. Software with functions of lines, area, lens setting.

* Volume, Size, Speed, Times, Waiting times can be numerically set. Precisely dispense without leaking.

* Adopted with "Panasonic" servo motor for XYZ motion control,deliver a precise and stable speedy motion dispensing.

* Employs a CCD camera which allows to view and precise position the dispenser route, provides tracking route, production counting. Save time in adjusting work & increase productivity.

* Plastic pistol and working area with heating system.

* A variety of dispensing can be fulfilled.

Specification
Product Videos
Product Accessories

Product Specifications

Model #	PME-R650A
Dispensing Range	(X) 650 x (Y) 300 (Z) 80 mm
Max. Speed	500mm /sec
Precision	+/- 0.015 mm
Repeatability	+/- 0.015 mm
Operating System	Windows 2000XP
Drive System	Panasonic Servo Motor/Needle Bearing
Operating Software	Self-developed dispensing software (CCD software)
Electric Source	AC 220V 50/60Hz ; 1.5KV
Unit Dimension	1200(L) x 950(W) x 1600(H) mm
Unit Weight	450 kg
Optional Device	1. MARKER with auto-positioning & adjusting function 2. Automatic in/out twin trays system 3. Glue pistols, automatic tray heating system 4. Multi-dispensing needles, Go with a variety of glue pistol and plastic barrel connection
