| Model # | PME-801LTA | PME-801LTB |
|---|---|---|
| No. of Spindles | 1 | 1 |
| Control Mode | Micro Computer Control, Auto Spreading & Auto Stop | Micro Computer Control, Auto Spreading & Auto Stop |
| Memory Capacity | 0~999 Inputs | 0~999 Inputs |
| Spindle Speed (rpm) | 1100 | 1100 |
| Wire Diameter | 0.5~1.6mm | 0.5~3.0mm |
| Traverse Width | 200mm | 200mm |
| No. of Spindles | Three Phase AC 1 HP | Three Phase AC 1 HP |
| Traverse Motor | Stepping Motor | Stepping Motor |
| Electric Source | AC200V 50/60Hz | AC200V 50/60Hz |
| Unit Dimension (mm) | 390(L) x 580(W) x 430(H) | 700(L) x 520(W) x 600(H) |
| Unit Weight | 52 kg | 52 kg |
