Fully Auto DIP Soldering Machine (Conveyor belt type)

PME-03CB

* Applicable for Vertical or Horizontal Coil or Relay component soldering work.

* Fully automatic conveyor feeding material, autoflux dipping, auto dip soldering and auto unloading.

* Different types of product may only need to manually adjust the bezel of conveyor for compatible feeding. No extra fixture or mold is required.

* Programmable angle rotation for dip soldering.

* Custom design according to customer's special soldering request and specification.

* Functional, stable, high efficiency, labor cost saving and simple operation.

Model #	PME-03CB
Operation	Control Touch Panel Interface
Control	PLC Servo Motor & PLC
Air Pressure	4~6 kg/cm2
Electric Source	AC220V 50/60Hz ; 3500W
Unit Dimension	920(L) x 700(W) x 1300(H) mm
Unit Weight	150kg
